European Audio Cable: Instrument Cables

Instrument Cables with Spiral Shield

Hi-Tech Controls, Inc, European & Domestic cable

Audio Cables, Digital Audio Cables, AES/EBU Digital Audio Cables, Multiparied, Pairs with Foil Shielding and Overall Foil Shielding, RoHS Approved, RoHS Compliant, Hi-Tech Controls, European
European Part Number: 400036
European Part Number: 400037
Type Instrument Cables Instrument Cables
Cable Construction 1 x 0.22 1 x 0.38
Conductor Material: Copper, bare Copper, bare
Conductor Insulation: PP Cell PE
Drain Wire: No Yes
Jacket Material: PVC PVC
Cable External Diameter: approx. 6.0 mm approx. 7.0 mm
Jacket Color: black black
>
Electrical Data European
Conductor Resistance Max.: 86 Ohm / km 55 Ohm / km
Insulation Resistance Min.: 1.0 GOhm x km 1.0 GOhm x km
Technical Data
Weight: Approximately 44.0 kg/km Approximately 55.0 kg/km
Min. Bending Radius (Laying): 60.0 mm 70.0 mm
Operating Temp.Range, min.: -25°C/-13°F -25°C/-13°F
Operating Temp.Range, max.: +70°C/+158°F +70°C/+158°F
Copper Weight: 7.6 kg/km 29.0 kg/km
Norms
  Halogen-free acc. to EN
50267-2-3
Halogen-free acc. to EN 50267-2-3
Type Instrument Cables Instrument Cables
Cable Construction 1 x 0.22 1 x 0.38
Conductor Material: Copper, bare Copper, bare
Conductor Insulation: PP Cell PE
Drain Wire: No Yes
Jacket Material: PVC PVC
Cable External Diameter: approx. 6.0 mm approx. 7.0 mm
Jacket Color: black black
Application
The HELUSOUND® instrument cable with spiral shield is a non-symmetrical, double shielded cable. This cable is specially suitable for connecting high ohmic components such as synthesisers, keyboards or guitars in professional stage and studio operation. The high-quality 1x0.38 special cable has an increased cross-section, a semi-conductor layer and a double spiral shield, which makes it suitable for the most stringent requirements of professional stages and studios.
Properties
  • Not available
Note
  • Not available
Cable Accessories
  • Coming Soon!
