Camozzi Index|Valves|Manual Valves


camozzi

CAMOZZI Valves
Manual, Mechanical & Air-Pilot

Foot Pedals

Download & Save as PDF File PDF Download

Foot Pedals (Cv = .06 - .91)

The pedals can be supplied either in the pneumatically-operated or in the electrically-operated
version. The pneumatically-operated type is available with a 5-way/2-position valve and 1/4" front ports which allow the fittings and silencers to be assembled more easily. A 3-way/2-position version can be obtained by simply plugging one of the two outlet ports, (2 or 4).
The electrically-operated type is available with a deviation single-pole contact micro-switch and a front wire outlet (PG9). The pedal can be operated as spring return or Detented, by switching the selector placed under the small red door as shown on the drawing (x).

Foot Pedal - Pneumatic

10-32 UNF, 5/32" OD: 3-way/2-position (Series 2)
10-1/4" NPTF, 5-way/2-position (Series 3)
Foot Pedal - Pneumatic
Part Number
354N-925TF
Technical Specifications
Valve group 5-way/2-position (Series 3); 3-way/2-position (Series 2)
Construction Spool-type (servocontrolled) (Series 3); Poppet type (Series 2)
Materials Anodized body, stainless steel spool, Buna-N seals, plastic casing nylon; brass poppet (Series 2)
Assembly Valve built into the pedal body
Threaded port sizes Series 3 1/4" NPTF, Series 2 5/32" OD, or 10-32 UNF
Installation On the floor
Operating temperature 32°F -125°F (dry air necessary down to 14°F)
Lubricant Not required; otherwise oil compatible with BUNA-N seals (3°-10°E) (ISOVG32 grade; 32 centistrokes)
Pneumatic Data
Operating pressure 2.5 - 10 bar (36 to 145 psi)
Rated pressure 6 bar (87 psi)
Rated flow Qn = 860 NL/Min., (30.36 SCFM)
CV Rating .91
*Qn flowrate (SCFM) determined with a supply pressure of 6 bar (87 psi), and with a pressure drop of 1 bar (14.5 psi). **Dimensions are in millimeters
Technical Drawing

Foot Pedal - Electrical

with Normally Closed/Normally Open contacts
Foot Pedal - Electrical
Part Number
3E2-925
Technical Specifications
Construction Deviation single-pole contact microswitch
Assembly Built into the pedal body
Port By means of wire PG9
Installation On the floor
Operating temperature 32°F -125°F




Electrical Data (Contact Rating)
  Load (A) Amps
Nominal
Voltage
resistive
N.C. / N.O.
light
N.C. / N.O.
inductive
N.C. / N.O.
motor
N.C. / N.O.
VAC 125 V
15 3 / 1.5 15 5 / 2.5
250 V
15 2.5 / 1.25 15 3 / 1.5
480 V 3 1.5 / 0.75 2.5 1.5 / 0.75
VDC 8 V 15 / 15 3 / 1.5 15 / 10 5 / 2.5
14 V 15 / 15 3 / 1.5 10 / 10 5 / 2.5
30 V 6 / 6 3 / 1.5 5 / 5 5 / 2.5
125 V 0.4 / 0.4 0.4 / 0.4 0.05 / 5 0.05 / 0.05
250 V 0.2 / 0.2 0.2 / 0.2 0.03 / 0.03 0.03 / 0.03
Note:
1. The inductive load is considered to have a load factor equal to 0.4 (a.c.) and a time constant equal to max. 7 m sec. (d.c.).
2. Light load means a load with start current equal to ten times the nominal current value.
3. Motor load means a load with a starting current equal to six times the nominal current value.
Technical Drawing
Series 2 Foot Pedal
10-32 UNF, 5/32" OD, 3-way/2-position Normally Closed
Series 2 Foot Pedal
Part Number Ports
235-925 10-32 UNF
234-925 5/32" O.D.
Technical Drawing
