Double insulated, According to VDE 600/1000 V AC
1800 V DC conductor/conductor
Sealcon, Inc, European & Domestic cable
European Part-No.
Description & No.
Conductors x cross-sec. mm2
Outer
Diameter
mm
Copper
Weight
kg/km
Weight
ca. kg/km
Conductor/ Jacket Color
AWG
704225
SOLARFLEX 1X2.5
4.5
24.0
42.0
black
14
705892
SOLARFLEX 1X2.5
4.5
24.0
42.0
blue
14
705891
SOLARFLEX 1X2.5
4.5
24.0
42.0
red
14
704226
SOLARFLEX 1X4
5.2
38.4
60.0
black
14
705776
SOLARFLEX 1X4
5.2
38.5
60.0
blue
14
705775
SOLARFLEX 1X4
5.2
38.4
60.0
red
14
704227
SOLARFLEX 1X6
5.9
57.6
82.0
black
14
705778
SOLARFLEX 1X6
5.9
57.6
82.0
blue
14
705777
SOLARFLEX 1X6
5.9
57.6
82.0
red
14
704228
SOLARFLEX 1X10
6.9
96.0
123.0
black
14
705894
SOLARFLEX 1X10
6.9
96.0
123.0
blue
14
705893
SOLARFLEX 1X10
6.9
96.0
123.0
red
14
704229
SOLARFLEX 1X16
8.3
153.6
190.0
black
14
706840
SOLARFLEX 1X16
8.3
153.6
190.0
blue
14
706839
SOLARFLEX 1X16
8.3
153.6
190.0
red
14
704230
SOLARFLEX 110 1X25
10.0
240.0
285.0
black
14
704231
SOLARFLEX 110 1X35
11.0
336.0
376.0
black
14
704232
SOLARFLEX 110 1X50
13.0
480.0
530.0
black
14
704233
SOLARFLEX 110 1X70
15.3
672.0
754.0
black
14
704234
SOLARFLEX 110 1X95
17.0
912.0
960.0
black
14
705738
SOLARFLEX 110 1X120
19.1
1152.0
1220.0
black
14
705739
SOLARFLEX 110 1X150
22.7
1440.0
1550.0
black
14
706288
SOLARFLEX 110 1X185
25.5
1776.0
1930.0
black
14
706289
SOLARFLEX 110 1X240
28.3
2304.0
2550.0
black
14
Technical
Data
European
Temperature Range -40°C to +90°C (-40°
F to +194°
F)
-40°C to +120°C (-40°
F to +152°
F) 3000 hours
Nominal Voltage According to VDE 600/1000 V AC, 1800 v DC conductor/conductor
AC Test Voltage, 50 Hz
10000 V
Minimum Bending Radius fixed installation approx. 4 x outer
diameters
flexing 10 x cable diameter
Approvals
Cable
Construction
Bare copper, tinned, finely stranded according to DIN VDE 0295 class 5 and IEC 60228 cl. 5
Double-insulated
Insulation cross-linked Polyolefin
Outer sheath cross-linked Polyolefin
Sheath colour black, red or blue
Application
The power of the wind, sun and water are alternative power sources which are always available and inexhaustible. These cables are intended for photo-voltaic systems. Photo-voltaic systems convert the energy of the sun directly into electric energy. The cable is UV-radiation and temperature resistant and can be used to connect individual solar cells. Because of their excellent weather resistance, these cables can also be installed outdoors, but not buried underground or laid in water. =
The product is conformed
with the EC Low-Voltage
Directive 73/23/EEC and
93/68/EEC.
Properties
Ozone resistant acc. to EN 50396
Weather und UV resistant acc. to HD 605/A1
Halogen-free acc. to EN 50267-2-1, EN 60684-2
Resistant to acid and bases acc. to EN 60811-2-1
Flame-resistant acc. to VDE 0482-332-1-2, DIN EN 60332-1-2, IEC 60332-1
Resistant to short-circuits up to 200�C thanks to their double insulation; short-circuits temperature 200�C/ 5sec
Anticipated service life - 25 years
Hydrolysis and ammoniac resistant
RoHS approved
Note
The product is conformed
with the EC Low-Voltage
Directive 73/23/EEC and
93/68/EEC.
