Active Components Switches for top DIN Rails

Switches for top DIN Rails

Description

Entry level industrial ETHERNET rail switch with store and forward switching mode and speeds of 10/ 100 and 1 OOOMbiVs. All
devices are maintenance-free and automatically adapt to your requirements. Switch with copper RJ45 and fibre optic port.
Ideal for using as media converters. Plug and play.

All devices have the follow ing features:
• Autocrossing (crossover adaption, straight or crossed)
• Autonegotiation (speec adaption 10/1 00/1 000)
• Autopolarity (pin correction on RJ 45 connector)
• Redundant pow er supply (2x DC In: 9.6 V to 32 V)
• Proliferation of options for all applications (e.g. ship building, vehicle construction, automation)
Compad design and low weight

Technical Data

• Voltage: 9.6 V DC-32 V DC
• Max. pow er consumption: 130 rnA
• Humidity: 1 O~95%
• Protection class: IP30
• cUL 508
• Accessories: Exclusive 19" mounting frame 802793 and power unit (e.g. RPS 15 Part No. 803178)
available to order.

,,..d , Part No.
Po".
Description
Operating temperature
"'" 4~ TP RJ4S. Ix Fx SC duplex o (to ·60'( l(Wl00 Mbttls , 802851
lxTPRJ45. l~fx SCduplex
SPIder 1T1I/1F~
,
803177
Spider 4Wl F~
10/100 Mbit/s
o (10 .60"(
SPIder 5 Tx 5x TP RJ45 O"C to .60"( 10/100 Mbttls 803123
5pide" STX 8x TP RJ45 O"C to .60"( 10/100 Mbtls • , 803324
SPIder II Glga 5Tns HC 5x TP RJ45, 2~ GE·SfP slots ·40 C 10 ·7fJ'C l(Wl00'l000 Mbitls , 803326
Spider II Giga 5T EE( 5x TP RJ45 -40"( to -70'( IO/l0CV!OOO Mbit/S 803125
Other vefsoons on request.
