NANOFLEX® HC* TRONIC-C EMC preferred type. flexible.
colour code to DIN 47100. screened. meter marking
HELUKABEl NANOFLEX® He TRON/C.C 711O 340MM'2727eOO10111207 «(
I RoHSI
Technical Data Cable Structure Properties
Special polyurethane data cables for • Bare copper conductor, fine wire • Resistant to UV radiation, oxygen,
2
electronic control according to stranded from 0.5 mm according to ozone, hydrolysis, microbes
DIN VDE 0245. 0812 DIN VDE 0295 cI.5 Self-extinguishing and flame retardant
• Temperature range or 0245 or IEC 60228 in accordance with VDE 0482-332-1-2,
0
Flexing -SoC to + 80 ( • Wire make-up for: DIN EN 60332-1-2/1EC 60332-1
0 2
Fixed installation -40°C to + 80 ( 0 .14 mm 18xO.l mm (conforms to DIN VDE 0472 Part 804
Pea k ope rating voltage 0.25 mm 14xO.15 mm Test method B)
2
2
(not for purposes of high current 0.34 mm 7xO.25 mm • The materials used in manufacture are
and power installation) • Special PVC core insulation TI2 free of silicone, cadmium and sub-
0.14 mm = 350 V according to DIN VDE 0281 Part , stances that impair paint wetting
2
2
> = 0.25 mm = 500 V • Core identification according • Good cleaning properties
• Test voltage to DIN 47100, but w ithout colour • Resistant to all standard
Core/core 1200 V repetition detergents
Core/screen 800 V • Cores stranded in layers with optimal Notes
Brea kdown voltage lay-lengths
Unscreened analogue type:
min. 2400 V • Foil wrapping NANOFLEX~ HC TRONIC
Insulation resistance • Drain stranded wire, tinned copper
*Hygienic Cable
min. 20 MOhm x km • Tinned copper braided screening,
Operating capacity coverage approx. 85%
(approx. value) at 800 Hz • Outer sheath from special fu ll
(ore/core at 0.14 mm 2 = 120pF/ m polyurethane TMPU according to
2
Core/core > = 0.25 mm = , SOpF/ m DIN EN 50363-10-2
Core/screen at 0.14 mm = 240pF/ m Sheath colour - light grey (RAL 7035)
2
Core/screen > = 0.25 mm2 = 270pF/m • With meter marking
Inductance approx. 0.65 mHJkm Application
Impedance approx. 78 Ohm
Screened special PUR cable for the food and beverage industry; outer sheath with
Coupling resist ance antimicrobial properties increases process reliability in all applications in which food
Max. 250 Ohm/km
and beverages are processed unpacked and unsealed, e.g. processing of dairy
Minimum b ending radius
products, meat, fish; production of convenience foods, brewery and beverage
Flexing' Ox cable 0 industry.
Fixed installation 5x cable 0
EMC = Electromagnetic compatibility. To optimise EMC charact eristics,
Radiation resistance
6
Up to 1 OOx' 0 cJ/ kg (up to '00 Mrad) w e recommend a large contact area for the copper braiding around the entire
circu m ference on both ends.
C E: = The product conforms to the EG Low-Voltage Directive 2006/95/ EG
