NANOFLEX® HC* SOO-C EMC preferred type,
cut-resistant. screened .. no inner sheath. meter marking
!~~~~:::_JC~_.!":!:ELUKA8EL NANOFLEXeHC 500-C 7G,0150MMf27125 300I500\1 001091104 C(
I RoHS I
Technical Data Cable Structure Properties
Special polyurethane sheathed cable Bare copper conductor, fine wire Resistant to UV radiation, oxygen,
according to DIN VDE 0245 Part 201 to stranded according to ozone, hydrolysis, microbes
1.5 mm2, according to DIN VOE 0295 cI. 5, BS 6360 cI. 5 Self-extinguishing and flame-retardant
DIN VDE 0245 Part 102 from 2 5 mm~ or IEC 60228 cI . 5 according to VDE 0482-332-1 - 2,
.. Tempe rature range Special PVC core insulation TI2 DIN EN 60332- 1-2/IEC 60332- 1
Flexing -SoC to + 80°(. according to DIN VDE 0281 Part 1 (conforms to DIN VDE 0472 Part 804
Fixed installation -4DoC to + 80°C Black cores with sequential white Test Method B)
Nomina l v o ltag e UclU 300/500 V numbering in accordance with • The materials used in manufacture are
Test vo lta g e 3000 V DIN VDE 0293 free of silicone, cadmium and sub-
Breakdown v o ltage Green-yellow earth core in t he outer stances that impair paint wetting
Min. 6000 V layer, 3 cores and more Good cleaning properties
Insulation resista nce Cores stranded in layers with optimal Resistant to all standard
Min. 20 MOhm x km lay-lengths detergents
Minimum b ending ra dius Separating foil
Flexing lOx cable 0 Braided screening of tinned Notes
Fixed installation, 5x cable 0" copper wires, coverage approx. 85%
G = with green-yellow earth core;
Radiatio n resist a n ce Outer sheath from special full x = without earth core (OZ).
6
Up to 1 OOxl 0 d / kg (up to 100 Mrad) polyurethane TMPU according to Unscreened analogue type:
Co upling resist a n ce DIN EN 50363- 10-2
Max. 250 Ohm/km Sheath colour - light grey (RAL 7035) NANOFLEX" HC 500
*Hygienic Cable
W ith meter marking
Application
Screened special PUR cable for the food and beverage industry; outer sheath with antimicro bial properties increases
process reliability in all applications in which food and beverages are processed unpacked and unsealed, e.g. processing of
dairy product s, meat, fish; production of convenience foods, brewery and beverage industry.
EMC = Electrom agnet ic compatibility. To optimise EMC characteristics, we recomm end a large contact area for the
copper braiding around t he ent ire circu m ference on both ends.
«( = The product conforms to the EG Low-Voltage Directive 2006l95/EG.
