NFPA 79 Edition 2007 -
Challenges and solutions ~
.lJ UL LISTED
Flexible Control Cables Servo and Motor Cables
TRAYCONTROL 500 & TRAYCONTROL SOO-C _ TOPFLEX 600 VFD _
Flexible, extremely oil-resistant control cables for open installation (ER) FleKible, extremely oil-resistant motor connection cables for open
Ul: TC-ER, PlTC·ER, ITC·ER, MTW, Dp·I, WTTC 1000V, Oil RES I & II installation (ER)
(SA: ClC-T( FT4, AWM VII NB FT4 UL: TC-ER. PlTC-ER, ITC-ER, MTW, WITC lOOOV, OIL RES I & II
See page 24-27 CSA: ClC-TC FT4, AWM VII AlB FT4
See page 31
TRAYCONTROL 600 & TRAYCONTROL 600-C _
Flexible, oil-resistant TRAY CABLE for open installation (ER) TOPFLEX' 650 VFD _
UL: TC·ER, PLTC·ER, ITC·fR, MTW, DP·', WTT( 100011, Oil RES I Flexible, extremely oil-resistant motor connection cables with control
(SA: ClC-TC FT4, AWM VII AlB FT4 pair for open installation (ER)
See page 28-30 UL: TC-ER. PlTC-ER, ITC-ER. MTW. WITC 10OOV, OIL RES I & II
CSA: ClC-TC FT4, AWM VII NB FT4
JZ 604 TC & JZ 604-FCY/YCY TC See page 32
Flexible, oil-resistant TRAY CABLE for open installation (ER)
UL: TC-ER TOPSER 600 VFD _
See Cables & Wires Catalogue 2009/20 I 0 page N 12 and 25 Highly-flexible. extremely oil-resistant motor connection cables for
open installation (ER)
UL: TC-ER. PlTC-ER, ITC-ER. MTW, WITC lOOOV, OIL RES I & II
Highly-flexible Control Cables CSA: ClC-TC FT4, AWM 1/11 NB FT4
See page 33
MULTI FLEX 600 & MULTI FLEX 600-C _ TOPSERV" 650 VFD _
Highly-flexible, extremely oil-resistant cables for open installation (ER) Highly-fleKible. extremely oil-resistant motor connection cables for
UL: TC-ER, PlTC-ER, ITC-fR. MTW, DP-1, WTTC 1000V, OIL RES I & II open installation (ER)
(SA: ClC-TC FT4, AWM VII AlB FT4
UL: TC-ER, PlTC-ER, ITC-ER. MTW. WITC IOOOV, OIL RES I & II
See page 35-38
CSA: CIC-TC FT4, AWM 1/11 AlB FT4
See page 34
Data Cables
HELUKAT® Copper Data Cables
TRAYCONTROL 300 & TRAYCONTROL 300-C _ HELUKAT® ISS UTP 4x2xAWG24/1 UL CMX 444
flexible, extremely oil-resistant data and control cables for open
HELUKAT® 200 FTPFLEX4x2xAWG26/7 UL CMX 444
installation (ER)* HELUKAT® 300 UTP 4K2xAWG24/1 UL CMX 444
UL: PLTC-ER, ITC-ER, CM, OIL RES I & II; HELUKAT® 300 U-STP 4x2xAWG26/7 Ul CMX 444
CSA: CIC-TC FT4, CMG See Cables & Wires Catalogue 2009/2010 page R46 etc.
See page 1 6-19
TRAYCONTROL 300 TP & _ Bus Cables
TRAYCONTROL 300-C TP PROFlnet Typ A Ul CMG or PLTC, CSA FT4
Flexible, extremely oil-resistant data and control cables for open installati- PROFlnet Typ B UL CMG or PLTC
on (ER)* PROFlnet Typ B SHIPLINE UL CMG or PLTC. CSA FT4
UL: PLTC-ER, ITC-ER, CM, OIL RES I & II; PROFlnet Typ C UL CMG
CSA: ClC-TC FT4, CMG Profibus L2 Torsion Ul CMX
See page 20-23 Profibus L2 Festoon UL CMX, CSA fT 4
Profibus SK inside Ul CMG, CSA FT 4
Profibus SK FRNC UL CM
Single Conductors Profibus SK drag chain UL CMX
DeviceNet,.PVC small UL CMG fT4
FIVE NORM DeviceNet ,. PVC thick UL CMG FT4
The jumper wire that meets five different standards See Data, Network & Bus Technology Catalogue Chapter 3
HAR: H05 V2-K/H07 V2-K;
UL: MTW, AWM Style 10269;
CSA: TEW bzw. AWM VAIB
See Cables & Wires Catalogue 2009/2010 page N92
THHN/THWM
Flexible jumper wire
UL: MTW, THHN, THWN, GASOLINE, OIL RES II,
AWM W-51554
See Cables & Wires Catalogue 2009/2010 page N94
• AWG22 ·AWG 16
