| "HSK-Diamond" Strain Relief |
Do you know of an application where galvanic corrosion could be devastating in an installation? To combat this problem, Sealcon now offers Hummel's Zinc Nickel Plated Brass Strain Relief Fitting. A Nickel Plated Brass (NPB) Strain Relief Fitting installed in an Aluminum Enclosure or Aluminum Panel exposed to the environment may eventually break down. An electro-chemical reaction takes place between a Nickel Plated part and Aluminum. Aluminum will corrode and most likely cause leakage. A Zinc Nickel Plated solution is much more corrosion resistant than a Nickel Plated Brass solution, especially in salt air (coastal) markets.
The picture to the right
shows our 3
options:
A) Standard Nickel Plated Brass
B) 'HSK Diamond' (ex. CD20MA-ZN)
C) Stainless Steel 303 (INOX) |
 |
| Nickel Plated Brass |
HSK Diamond |
Stainless Steel 303
(INOX) |
In most cases, our standard NPB Strain Relief Fitting will suffice. The Stainless Steel is the most expensive alternative, however corrosion resistant and rugged. The HSK-Diamond is somewhere in between but really a nice and economical solution for harsh environments. The HSK-Diamond costs about 2.5 times more than a standard NPB Strain Relief Fitting, which is still a huge savings compared to INOX (Stainless Steel 303) Fittings, which cost about 7 times as much as a NPB fitting.
Possible markets for the "HSK Diamond":
· Contaminated and ozone loaded air
· Coastal (salt water) environments
· Pollution Control Equipment
· Metrological Equipment (Antennas)
· Telecom
· Marine
· Navy
All sizes available upon request.
|
 |
HSK Diamond Strain Relief Technical Information
• Pressure Rating: 150 PSIG (10 BAR) NEMA 4x & 6 (Submersible) - IP 68 / IP 69 K
• Spline Bushing & Form Seal: Nylon 6/6, V0: Flame Resistant, Halogen & Phosphorus Free, Self
Extinguishing, Non-Toxic
• O-Ring & Seal Ring: Buna-N/Polyethylene, Viton® (Optional)
|
|
 |
|
|
|
