Flexible, Number Coded, 0.6/1kV, Copper-Shielded, EMI Preferred Type
http://www.hitechcontrols.com/cables/control_cable/pvc_shielded/jz-600_y_cy_ul_csa.html
Application:
Wiring cable for measuring and controlling purposes in tool machinery, conveyor belts and production lines, for plant installations, air conditioning and in steel production plants and rolling mills. Suitable for installation for flexible use for medium mechanical stresses with free movement without tensile stress or forced movements in dry, moist and wet rooms as well as outside (fixed installation). Is not suitable to be used as direct burial or as underwater cable. Interference-free transmission of signals and pulses is assured by the high degree of shielding.
EMI = Electromagnetic Interference
To optimize the EMI features we recommend a large round contact of the copper braiding on both ends.
Properties
- Extensively oil resistant
- For chemical resistance, see table Technical Information
- Resistant to ultra violet rays (building with black jacket)
- PVC self-extinguishing and flame retardant according to DIN VDE 0482-332-1-2, DIN EN 60332-1-2 / IEC 60332-1 (equivalent DIN VDE 0472 part 804 test method B) VW1, FT1
- The materials used in manufacture are cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquers
Cable Construction
- Bare copper, fine wire conductors according to DIN VDE 0295 cl. 5, BS 6360 cl. 5 and IEC 60228 cl. 5
- Special PVC conductor insulation TI2, to DIN VDE 0281 part 1, class 43 UL Std. 1581
- Black conductors with sequential numbering imprinted in white, according to DIN VDE 0293
- Green-yellow earth conductor in the outer layer (3 conductors and above)
- Conductors stranded in layers with optimal lay-length
- PVC-insulated inner jacket TM2, to DIN VDE 0281 part 1, class 43 UL-Std. 1581
- Braided shielding of tinned copper wires, coverage approx. 85%
- Special PVC outer jacket TM2, to DIN VDE 0281 part 1 class 43 UL Std. 1581
- Color: Black (RAL 9005) or Gray (RAL 7001)
Technical Data
- Special PVC control cables
- Adapted to DIN VDE 0276 part 627, DIN VDE 0281 part 13, with insulation thickness for 1 kV type and UL Std. 758 Style 21179
- Temperature Range: Flexing -5°C to +80°C (+23°F to +176°F), Fixed Installation -40°C to +90°C (-40°F to +194°F)
- Nominal voltage U 1000 V
- Test voltage 4000 V
- Breakdown voltage min. 8000 V
- Insulation Resistance Min. 20 MOhm x km
- Power Rating According to DIN VDE 0298
- Minimum Bending Radius Flexing 10x cable Ø, Fixed Installation 5x cable Ø
- Radiation Resistance Up to 80×106 cJ/kg (up to 80 Mrad)
- Coupling Resistance Max. 250 Ohm/km
http://www.hitechcontrols.com/cables/control_cable/pvc/jz_600_ul_csa.html
Flexible, Number Coded, 0.6/1kV, UL & CSA Approved, AWG: 20 – 4, RoHS, Deca BDE, Extensively oil resistant For Chemical Resistance, see table Technical Information Resistant to ultra violet rays (building with black jacket), PVC self-extinguishing and flame retardant, cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquers.
 http://www.hitechcontrols.com/cables/control_cable/pvc/jz_500.html
• Flexible, number coded, oil resistant
• Applications: tool machines, conveyor belts, production lines in machinery production, air-conditioning, steel production
Clean Room approved
 http://www.hitechcontrols.com/cables/halogen_free_security_cables/control/jz_500_hmh.html
• Flexible Control Cable, Halogen-Free, Extremely Fire Resistant, Oil Resistant
• Halogen-free flexible control cable, adapted to E DIN VDE 0281 part 14 …and DIN VDE 0281 part 13
• Temperature Range: Flexing -15°C to +70°C (+5°F to +158°F), Fixed Installation
-40°C to +70°C (-40°F to +158°F)
• Nominal Voltage U0/U 300/500 V
• Test Voltage 2000 V
• Minimum Bending Radius: Flexing approx. 12.5x cable Ø, Fixed Installation approx. 4x cable Ø
• Radiation resistance: Up to 100×106 cJ/kg (up to 100 Mrad)
• Applications: tool machines, coveyor belts, production lines in machinery production, air-conditioning, steel production
Clean Room approved
For open installation TC-ER, PLTC-ER, ITC-ER, NFPA 79 Edition 2007
http://www.hitechcontrols.com/cables/control_cable/pvc/traycontrol-500.html
Application
HELUKABEL® TRAYCONTROL 500 is a flexible, oil-resistant control cable. The special combination of TC-ER, PLTC-ER and ITC-ER allows this cable to be used as a connecting cable for industrial plant and machinery in accordance with NFPA 79 Edition 2007. Approved for open, unprotected installation in cable trays to the machine. Its outstanding oil resistance (OIL RES I & II) guarantees a long service life for industrial applications in dry, damp and wet environments.
Recommended applications: production lines, bottling plants, machine construction, switch cabinets, conveyor systems, packaging machines, automotive industry.
CE = The product conforms to the EG Low-Voltage Directive 2006/95/EG
Technical Data
• PVC control cable according to UL Standard 1277
• Temperature range: Flexing -5°C to +90°C / Fixed installation -40°C to +90°C
• Nominal voltage: TC 600 V, AWM: 1000 V, TC Wind Turbine (WTTC): 1000V, Test voltage 3000 V
• Minimum bending radius: Flexing 4x cable Ø
• Insulation resistance: Min. 20 MOhm x km
• Radiation resistance: Up to 80×106 cJ/kg (up to 80 Mrad)
Cable Structure
• Bare copper conductor, fine wire stranded
• Special PVC core insulation with transparent nylon skin
• Black cores with continuous white numbering
• Green-yellow earth core in the outer layer, 3 cores and more
• Cores stranded in layers with optimal lay-lengths
• Separator
• Special PVC outer jacket
• Jacket/Sheath color – grey (RAL 7001)
• With length marking in feet
Properties
• Self-extinguishing and flame retardant in accordance with CSA FT4
• The materials used in manufacture are free of silicone, cadmium and substances that impair paint wetting
• Tests
UL: TC-ER, PLTC-ER (AWG 18 – AWG 12), ITC-ER (AWG 18 – AWG 12), MTW, NFPA 79 2007, WTTC 1000V, DP-1, OIL RES I & II, 90°C dry / 75°C wet, Class 1 Div. 2 per NEC Art 336, 392, 501, crush impact test in accordance with UL 1277
CSA: c(UL) CIC-TC FT4, CSA AWM I/II A/B FT4
 A multitude of applications needs the inset of particular special cable constructions. Corresponding to the customer’s requirements those cables may be constructed with different stranding elements and cross-sections of the cable. In this case we are speaking about combination or hybrid cables. Application technical reasons may require using different insulating materials, choosing special stranding types or special shielding, for example multiple or mixed shielding.
http://www.hitechcontrols.com/cables/servo_cable/selection_pages/servo_feedback_motor_selection.html
Outer Jacket Blue, Intrinsic Safety, Flexible, EMI Preferred Type
http://www.hitechcontrols.com/cables/control_cable/intrinsic_safe/oz_bl_cy.html
Application:
For hazardous areas the cables with special marking (blue) (hazard type-i-) used as flexible control and measuring cables to meet the requirements for the installation of electrical apparatus. These installations are not grounded and require a separate power circuit. Those cables are not suitable for underground laying.
The copper braided shielding ensures the transmission of data signals and free from interference.
EMI = Electromagnetic Interference
To optimize the EMI features we recommend a large round contact of the copper braiding on both ends.
CE= The product is conformed with the EC Low-Voltage Directive 73/23/EEC and 93/68/EEC
Cable Construction
- Bare copper, fine wire conductors bunch stranded to DIN VDE 0295 cl. 5, BS 6360 cl. 5 and IEC 60228 cl. 5
- Conductor insulation of special PVC Z 7225
- Black conductors with white continuous figure imprint to DIN VDE 0293 without ground conductor
- Conductors stranded in layers with optimal lay-length
- Conductor wrapping of plastic foil
- Braiding, tinned copper wire shielding, approx. 85% coverage
- Special PVC outer jacket TM2, to DIN VDE 0281 part 1 and HD 21.1
- Color: Blue (RAL 5015)
Properties
- Extensively oil resistant
Chemical Resistance – see table Technical Information.
- PVC self-extinguishing and flame retardant according to VDE 0482-332-1-2, DIN EN 60332-1-2 / IEC 60332-1 (equivalent DIN VDE 0472 part 804 test method B)
- The materials used in manufacture are cadmium-free, contain no silicone and are free from substances harmful to the wetting properties of lacquers
Technical Data
- Control cable, special PVC with blue outer jacket for hazardous areas to hazard type -i- (=intrinsically safe)
- For intrinsically safe installation marking as per DIN EN 60079-14 and IEC 60079-14 section 12.2.2 (VDE 0165 part 1)
- Temperature Range Flexing -5°C to +80°C (+22°F to +176°F), Fixed Installation -40°C to +80°C (-40°F to +176°F)
- Nominal Voltage U0/U 300/500 V
- Test Voltage 3000 V
- Breakdown Voltage min. 6000 V
- Insulation Resistance Min. 20 MOhm x km
- Mutual Capacitance Conductor/conductor approx. 140 nF/km, Conductor/screen approx. 187 nF/km
- Inductance approx. 0.68 mH/km
- Coupling Resistance Max. 250 Ohm/km
- Minimum Bending Radius Flexing 10x cable Ø Fixed Installation 5x cable Ø
- Radiation Resistance Up to 80×106 cJ/kg (up to 80 Mrad)\
 http://www.hitechcontrols.com/cables/control_cable/drag_pur_shielded/multiflex_512_c_pur_ul_csa.html
This cable is specially made for Drag Chains and Track Cable. It is Halogen-Free, Shielded, and an EMI Preferred Type.
 The high-performance cable for wind power turbines with global approvals!
HELUKABEL® offers a Wind Turbine Cable that is specially designed for torsional application in cable loops and successfully passed the challenging CSA FT4 flame test! The rigors of wind power environments make high demands on the quality of cable: mechanical load, aggressive oil, extreme temperatures. While in one part of the world wind turbine cables are required to resist extreme heat, in another ice threatens their operability. Based on over 30 years of experience in designing and producing wire & cable, the faith in high-quality raw materials and constant research & development HELUKABEL® developed a product that withstands these forces and therefore exactly meets the requirements of wind turbine manufacturers.
Properties of the HELUWIND® WK 137-Torsion FT4:
- extremely abrasion resistant with a significantly longer lifetime than rubber cable
- halogen-free and highly flame-retardant
- extremely oil resistant; the cable was tested successfully for the aggressive oil effectively used in wind power turbines
- superior twisting and flexing performance: the torsion application of +/-150° per 1m is tested in more than 16,000 cycles in the 27 ft high HELUKABEL® research tower that reproduces construction and conditions of the cable loop within a wind tower
- UV- and seawater resistant (suitable for offshore-installation)
- temperature range of -40°C to 90°C (UL: 80°C)
- approvals: UL, CSA, RoHS, CE (VDE and WTTC in preparation)Because of these multiple properties the HELUWIND® WK 137-Torsion FT4 may be applied under all climatic conditions. This provides long-term cost benefits to the manufacturers of wind turbines: it releases them from managing and stocking different types of cables for various locations of installation. In this manner the assembly of the wind power turbines is independent from its installation location.HELUKABEL® is an international manufacturer and supplier of wires, cables and cable accessories with sales of 500 Million USD in 2008. The company specializes in flexible and continuous flex cable as well as products for renewable energy applications: The first custom made cable for wind power applications was developed 15 years ago. The companies’ headquarters in Germany and warehouses in over 40 countries serve costumers all over the world. Products complying with the following standards are in stock or will be manufactured on request: UL, CSA, BS, HAR, VDE, TÜV, CCC, GOST-R.
 SJT/, CE POWER CORDAGE & CONTROL CABLES
http://www.hitechcontrols.com/cables/installation-cables/selection-pages/contents.html
This flexible PVC cable is perfect for the Domestic/Export appliance manufacturing industry. (Colors: Black, White & Orange) One cable with all the needed approvals helps reduce inventory and the worry of selecting the correct cable for exporting. Applications include household, kitchen, and office appliances in dry and wet environments, both indoors and outdoors. Available with 2 to 5 conductors and 18 to 12 AWG (.75 to 4 mm2). Special order sizes and colors available. We have access to over $30 Million of HELUKABEL’s Inventory to help service the U.S.A. and Canadian markets.
|
|
